CPDLC Off and Running
Controller-Pilot Data Link Communications (CPDLC), the government-industry program to reduce frequency congestion and increase communications clarity and reliability, became a reality on Oct. 7, 2002, at 7:38 a.m., as Miami Center sent the first CPDLC message to an American Airlines Boeing 757. The carrier planned to have 12 Boeing 757s and four B767s CPDLC-equipped by November 2002. "Things have been working reasonably well," says Frank Cheshire, data link project coordinator for American.
American is the launch carrier for CPDLC Build 1, but more participants will take part. The U.S. Air Force, with one Learjet, is to join up this month. Delta Air Lines is expected to come in with four aircraft by January 2003. FedEx Express also is to join the Miami area activity with six aircraft some time in 2003, according to the Federal Aviation Administration (FAA), and Continental Airlines wants to take part.
"Miami…is a learning lab of what CPDLC has to offer," says John Thornton, director of FAA’s Free Flight program. "Gains for relief to voice systems will come when we move out from Miami and go to other places."
Build 1 services include transfer of communications, initial contact, altimeter settings and message text. Pilots also have quick-response buttons for "willco" (will comply), "unable," "negative" and "roger." Pilots will see messages on the communications management unit (CMU) screen, where aircraft communications addressing and reporting system (ACARS) messages appear. CPDLC messages are stored on the CMU, FAA says.
The data link backup is voice communications, Thornton says. FAA initially is trying CPDLC with non-critical air traffic communications. However, "as we build and go out further, we’ll look to see if we need a data link backup or a voice backup." Visit www.faa.gov.
T2CAS Milestones
The combination traffic and terrain awareness and warning system, developed by Phoenix, Ariz.-based ACSS, made its maiden flight and captured a large customer in October. ACSS first flew its T2CAS in a Raytheon Beech King Air C90 on Oct. 23, and plans to secure the system’s certification by the end of 2002. The maiden flight, in an aircraft that ACSS recently purchased, included testing of the T2CAS’ terrain awareness warning system (TAWS) function.
In addition, ACSS recently announced that it received an order for 16 T2CAS ship sets from the U.S. Customs Service. This is in addition to an order for Mode S/IFF (identification friend or foe) transponders for the Custom Service’s P-3 aircraft. The agency joins Northwest Airlines, FedEx Express, Aeromexico and Virgin Express in ordering the T2CAS.
The T2CAS combines technologies from the two companies that hold an interest in ACSS, L-3 Communications and Thales Avionics. Visit www.l-3com.com.
Making King Airs Digital
Stevens Aviation has added to its list of U.S. government contracts with a recent order to upgrade 19 of the U.S. military’s Raytheon Beech King Air 200 aircraft. The contract represents the largest project in the aircraft services provider’s 52-year history. Stevens has begun working on the first two King Airs in its four-year-old facility in Greenville, S.C., where it has 33 employees dedicated to the program. "We’re taking an analog airplane and making it digital," says Jim Williams, project manager and avionics specialist at Stevens. The program involves installing a new center console and all new wiring, he adds.
The new King Air panel will include Rockwell Collins’ FDS 2000 electronic flight instrument system (EFIS), TCAS 94 traffic alert collision avoidance system, and weather radar. It will be fitted with five liquid crystal displays (LCDs). Honeywell will provide its Mark 7 enhanced ground proximity warning system (EGPWS), and L-3 Communications will furnish both the digital flight data recorder and cockpit voice recorder. Stevens also will install dual digital transponders and three secure GPS receivers in the King Airs.
Each aircraft will require about 10 weeks for completion, according to Williams. With multiple aircraft in the Greenville facility, Stevens will complete all 19 aircraft in little more than 20 months, he adds. Visit www.stevensaviation.com.
Gulfstream 150 Cockpit
Gulfstream Aerospace has selected the Rockwell Collins Pro Line 2 avionics suite for the G150 business jet. The G150’s flight deck will be fitted with four 12-by-10-inch liquid crystal displays (LCDs), the Pro Line 21 CNS (communication, navigation and surveillance) sensors, supporting data communications; the Collins FMS-6000 flight management system (FMS) with integrated V speeds; the AHS-3000 attitude heading reference system; and a dual-channel automatic flight control system. Options include a checklist feature and Collins’ new file server unit, which links the partitioned processing, Ethernet interfaces and LCDs to present graphical weather, enhanced maps and electronic charts. Another option is the presentation of a three-dimensional FMS flight plan map. Gulfstream plans to complete certification and first customer delivery of the G150 in mid-2005.
Visit www.rockwellcollins.com and www.gulfstream.com.
RNP at SFO
Alaska Airlines, a pioneer in required navigation performance (RNP), is on the verge of government approval for an RNP approach to San Francisco’s parallel runway 28R. The Federal Aviation Administration (FAA) could bless the privately developed RNP 0.11 procedure–which would be the lowest in the United States–this year. The carrier will fly the procedure with Boeing 737-400s, -700s and -900s.
RNP 0.11 means an aircraft must be within about 0.11 nautical mile (670 feet or 204 meters) laterally of the centerline with a 95 percent probability. But typical aircraft performance will be right on the flight path centerline, says Mike Adams, Alaska’s managing director-technical operations, based on the airline’s RNP experience, conservative engineering assumptions and the avionics’ robust technical design. The carrier already flies 13 RNP approaches in Alaska.
"The problem at San Francisco is that, when the ceiling is below 3,000 to 3,500 feet, there are no visual approaches to the parallel runways, 28L and 28R," which are only 750 feet apart, Adams says. Traffic narrows to a single stream, allowing 30 approaches an hour, versus 60 approaches. With the new approach, Alaska could maintain dual runway use down to 1,400-foot ceilings, increasing airport capacity for other users, as well. After breaking through the clouds at that altitude, a pilot would have about 30 seconds to visually acquire the other aircraft and determine whether to land before reaching the 1,092-foot decision altitude.
Approach plates for the procedure will start with three levels–RNP 0.11, RNP 0.2 and RNP 0.3–allowing aircraft not certified to RNP 0.11 to take advantage of the approach. Continental, United, Delta and American, as well as FAA, support RNP approaches at San Francisco, Adams says.
Avionics Expo
An exhibition and conference dedicated to the avionics industry, Avionics Expo Euro ’03, has been launched and will take place in Wiesbaden, Germany, Nov. 20-21, 2003. The event will spotlight new products and technologies in aerospace electronics for both civil and military aircraft and in both the cockpit and the cabin. The conference, tentatively titled "Tomorrow’s Avionics for Tomorrow’s Airspace," will cover the modernized airspace in which aircraft will fly and what avionics will be required to fly in that airspace.
UK-based Simply Events is organizing the event. It is working with an advisory board that includes representatives from the Aircraft Electronics Association (AEA), Becker Avionics, Boeing, Electronics Cable Specialists, Mid-Continent Instrument Co. and others. Avionics Magazine, a sponsor of Avionics Expo Euro ’03, will organize the conference. Visit www.avionicsexhibition.com.
Correction
An article on simulation in our October issue incorrectly identified a United Airlines flight simulator. The simulator is a Boeing 747-400.
